Unico M Series User Manual

Bulletin 30-020.007
Copyright © 2019 Unico Inc. Page 29
A00850-G01
Spacer Module
Vertical Filler
Panel
A00863/A01774/
A00850-G01 Spacer Module
For M2430 and 3642 Units
For M4860 Units
Ensurefiller panel
is removed
Ensure filler panel is installed
M2430/3642/4860V2
Vertical PlenumModule
M2430/3036/3642
Cooling Module
A00863-G01/A01774-G01/
A00850-G01
Spacer Module*
M2430/3036/3642/4860B
Blower Module
UPC-104-2430/3036/3642/4860
Access Panel (Insulated)
Shipped with HW-XXXX
HW-2430/3036/3642/4860
Hot WaterCoil
*A00863-G01, A01774-G01, A00850-G01 are shipped with the M2430V2, M3036V2, & M3642V2, respectively.
The M4860V2 is not shipped with a spacer module. The M4860C is shipped with the A00850-G01.
M4860C
Cooling Module
Vertical Filler
Panel
Top Panel
NewBottom Panel
(sent withMV)
Remove
Latches
Airflow
MXXXXR1
MultipleReturn Module
For Multiple Return Systems
UNICO SYSTEM
M-Series Vertical Installation
Pitch Bottom Panel
Secondary Drain Pan
