the cuvette is in the light path (Push the rod in). Close the lid.
Analyze Sample
For different user requirements, we have provided different test methods.
Basic Mode
Push the blank cuvette into the light path. In main menu (Fig7),press【1】 to
enter “Basic mode” test . After automatically blanking, it will display as Fig 18
(automatic changer installed) or Fig 19 ( automatic changer uninstalled) and
wait for the operator. 【ESC/STOP】to exit.
Note: .If no automatic changer installed “cell #1” and“Max E” will disappear
in Fig18
WL : 656.1nm 12: 35: 27
0.000 Abs
D2
W
Cell #1
Max E
F1:Unit F2:Mode F3:F Factor F4:Standard
Fig18
WL : 656.1nm 12: 35: 27
0.000 Abs
D2
W
Max E
F1:Unit F2:Mode F3:F Factor F4:Standard
Fig19
J Test
There are three modes (T%,Abs,conc/factor) for you to select by pressing
【F2】to make choice.
WL : 656.1nm 12: 35: 27
0.104 Abs
D2
W
Cell #1
Max E
F1:Unit F2:Mode F3:F Factor F4:Standard
Fig 20
To Next Page
