UNICORECOMM UM960 User Manual

UM960 User Manual
UC-00-M34 EN R1.0 Hardware 5
2 Hardware
2.1 Dimensions
Table 2-1 Dimensions
Symbol
Min.(mm)
Typ. (mm)
Max. (mm)
A
15.80
16.00
16.50
B
12.00
12.20
12.70
C
2.40
2.60
2.80
D
0.90
1.00
1.10
E
0.20
0.30
0.40
F
1.40
1.50
1.60
G
1.00
1.10
1.20
H
0.70
0.80
0.90
J
3.20
3.30
3.40
N
2.90
3.00
3.10
P
1.30
1.40
1.50
R
0.99
1.00
1.10
X
0.72
0.82
0.92
φ
0.99
1.00
1.10
