2.3 Electrical Specifications
2.3.1 Absolute Maximum Ratings
Table 2-3 Absolute Maximum Ratings
Parameter
Symbol
Min.
Max.
Unit
Power Supply Voltage
VCC
-0.3
3.6
V
Input Voltage
V
in
-0.3
3.6
V
GNSS Antenna Signal Input
ANT_IN
-0.3
6
V
Antenna RF Input Power
ANT_IN input
power
+10
dBm
External LNA Power Supply
VCC_RF
-0.3
3.6
V
VCC_RF Output Current
ICC_RF
100
mA
Storage Temperature
T
stg
-55
95
°C
2.3.2 Operational Conditions
Table 2-4 Operational Conditions
Parameter
Symbol
Min.
Typ.
Max.
Unit
Condition
Power Supply Voltage
8
VCC
3.0
3.3
3.6
V
Maximum VCC Ripple
V
rpp
0
50
mV
Working Current
9
I
opr
145
180
mA
VCC=3.3 V
VCC_RF Output Voltage
VCC_RF
VCC-0.1
V
VCC_RF Output Current
ICC_RF
50
mA
Operating Temperature
T
opr
-40
85
°C
Power Consumption
P
480
mW
8
The voltage range of VCC (3.0 V ~ 3.6 V) has already included the ripple voltage.
9
Since the product has capacitors inside, inrush current occurs during power-on. You should evaluate
in the actual environment in order to check the effect of the supply voltage drop caused by inrush
current in the system.
