UNICORECOMM UM980 User Manual

UM980 User Manual
4 Introduction UC-00-M32 EN R1.0
Warm Start < 20 s
Hot Start < 5 s
Initialization Time
2
< 5 s (Typical)
Initialization Reliability
2
> 99.9%
Data Update Rate
50 Hz
6
Positioning
Differential Data
RTCM 3.X
Data Format
NMEA-0183, Unicore
Physical Characteristics
Package
54 pin LGA
Dimensions
22 mm × 17 mm × 2.6 mm
Weight
1.88 g ± 0.03 g
Environmental Specifications
Operating Temperature
-40 °C ~ +85 °C
Storage Temperature
-55 °C ~ +95 °C
Humidity
95% No condensation
Vibration
GJB150.16A-2009, MIL-STD-810F
Shock
GJB150.18A-2009, MIL-STD-810F
Functional Ports
UART × 3
I
2
C
*
× 1
SPI
*
× 1
Slave
CAN
*
× 1
Shared with UART3
* I
2
C, SPI, CAN: reserved interfaces, not supported currently
6
Supports 50 Hz after firmware upgrade
