UNICORECOMM UM982-EB - LED Indicators

UM982-EB User Manual
12 LED Indicators UC-08-M31 EN P1.0.3
Figure 4-4 Antenna Feed Circuit on the Bottom of UM982-EB
5 LED Indicators
There are LED indicators on UM982-EB to indicate the working status of each functional
unit.
Figure 5-1 LED Indicators
