6 WPP 15 E | Version 1.02
Intended use
3 Intended use
The hydraulic workshop press is intended for use in the
automotive and mechanical engineering industry only. It
is suitable for pressing in/out bearings, bushes, em-
bossing, deformation and stamping. The capacity
stated in the technical data must not be exceeded. Do
not apply excessive force to workpieces. Check pres-
sure loads on the pressure gauge.
The hydraulic workshop press must be operated by per-
sons who have been instructed on the use of the ma-
chine only.
The intended use shall also include adherence to all in-
formation in these operating instructions. Any other use
or use beyond the intended use shall be deemed mis-
use.
Conversions at one's own responsibility or modifications
to the workshop press may invalidate the CE conformity
of the workshop press and this shall not be permitted.
Stürmer Maschinen GmbH shall not assume any liability
for design-based or technical modifications to the work-
shop press.
Unintended use of the workshop press as well as non-
observance of the safety instructions or operating in-
structions shall exclude the manufacturer's liability for
any resulting damage or injury and this shall void any
warranty claims!
Any claims resulting from damage due to unintended
use shall be excluded.
3.1 Foreseeable misuse
If the intended purpose of the workshop press is ob-
served, there is no actually foreseeable misuse that may
cause hazardous situations involving personal injury.
3.2 Remaining risks
Even when observing all safety instructions, operation of
the workshop press involves the remaining risks de-
scribed in the following.
All persons working with the workshop press must be
aware of the remaining risks and observe the instruc-
tions to prevent these remaining risks from causing ac-
cidents or damage:
- Risk of pinching upper limbs during operation
- It may be necessary to remove installed protective
equipment to configure and equip the machine.
This causes various remaining risks and potential
hazards each user must be aware of.
4 Technical data
4.1 Table
4.2 Environmental conditions
WARNING!
Risk of misuse!
Misuse of the machine may cause hazardous situa-
tions.
- Operate the machine within the performance range
stated in the technical data only.
- Do not bypass or disarm safety equipment.
- The workshop press must be operated in techni-
cally perfect condition only.
Model WPP 15 E
Compression force 15 t
Foot width x depth 700 x 540 mm
Total height 1616 mm
Inside width 500 mm
Work area 173 - 985 mm
Piston stroke 160 mm
Piston travel 169 mm
Weight 91.5 kg
Model WPP 15 E
Operating temperature -5°C to 40°C
Storage temperature -25°C to 55°C
Transport temperatures -25°C to 70°C (< 24 h)
Altitude range max. 1,000 m
Humidity max. 85% relative hu-
midity
Working environment Non-flammable, dry and
free from dust
