General| Wireless Standards | 802.11 a/b/g/n/ac |
|---|---|
| Frequency Band | 2.4 GHz, 5 GHz |
| Antenna Gain | 2.4 GHz: 3 dBi, 5 GHz: 4 dBi |
| Maximum Power Consumption | 8.5W |
| Wireless Security | WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) |
| Supported Voltage Range | 44-57VDC |
| Max. TX Power | 2.4 GHz: 20 dBm, 5 GHz: 20 dBm |
| BSSID | Up to 4 per Radio |
| Operating Temperature | -30 to 70° C (-22 to 158° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
| MIMO | 2x2 |
| Power Method | Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Networking Interface | 10/100/1000 Ethernet |
| Mounting | Wall, Pole |
| Antennas | 2 Dual-Band Antennas |
| Wireless Speed | 867 Mbps |
| Data Rate | Up to 867 Mbps (5 GHz), 300 Mbps (2.4 GHz) |
