UniFi AC Mesh User Manual

Gain is entered manually. Note the requirements and antenna types listed below.
Certified Antenna Types
This radio transmitter FCC ID: SWX-UAPACM / IC: 6545A-UAPACM has been
approved by FCC / ISED Canada to operate with the antenna types listed below with
the maximum permissible gain for each antenna type indicated. Antenna types not
included in this list or having a gain greater than the maximum gain indicated for that
type, are strictly prohibited for use with this device.
Antenna Frequency Gain
2 Omni (default) 2.4 GHz
5 GHz
3 dBi
4 dBi
1 Panel 2.4 GHz
5 GHz
10 dBi
15 dBi
Specifications
UAP-AC-M
Dimensions 353 x 46 x 34.4 mm
(13.9 x 1.81 x 1.35")
Weight 152 g (5.36 oz) with Antennas
Networking Interface (1) 10/100/1000 Ethernet Port
Buttons Reset
Power Method 24V Passive PoE (Pairs 4, 5+; 7, 8 Return);
802.3af Alternative A (Pairs 1, 2+; 3, 6 Return)
Power Supply 24V, 0.5A Gigabit PoE Adapter (Included)
Supported Voltage Range 44 to 57VDC
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

UniFi AC Mesh Specifications

General

Brand	UniFi
Model	AC Mesh
Category	Wireless Access Point
Language	English
