VIPER MULTI 165
OPERATING MANUAL
3. Machine Specifications
VIPER MULTI 165
3.1 Technical Data
Parameter Values
SKU U11006K
Primary Input Voltage 240V Single Phase
Supply Plug 10 AMP
Ie (A) 10.0
Rated Output 30A/15.5V - 165A/22.3V
No Load Voltage (V) 64
Protection Class IP21S
Insulation Class H
Minimum Generator (kVA) 9.0
Dinse Connector 35/50
Standard AS/NZ60974-1
Welds Mild Steel, Stainless Steel, Cast
Iron, Silicon Bronze, Aluminium,
Copper
Warranty (Years) 2
3.2 MIG Specifications
Parameter Values
MIG Welding Current Range 30-165A
MIG Duty Cycle @ 40°C 10% @ 165A
60% @ 68A
100% @ 52A
MIG Wire Size Range 0.6-0.9mm
MIG Wire Spool Size 1kg / 5kg
MIG Welding Thickness Range 1-8mm
Drive Roller SIze 30/10
3.3 TIG Specifications
Parameter Values
TIG Function Type DC Lift Arc
TIG Welding Current Range 20-160A
TIG Duty Cycle @ 40°C 10% @ 160A
60% @ 65A
100% @ 50A
TIG Welding Thickness Range 1-6mm
3.4 STICK Specifications
Parameter Values
STICK Welding Current Range 20-140A
STICK Duty Cycle @ 40°C 10% @ 140A
60% @ 58A
100% @ 45A
STICK Electrode Range 2.5-3.2mm
STICK Welding Thickness Range 2-8mm
3.5 Size & Weight
Parameter Values
Dimensions (mm) 513x206x391mm
Weight (kg) 9.8kg
