Unipower Sageon Micro Power Module User Manual

Operation Sageon Micro Power Module Manual
PM990-4207-00, Rev 6
5-6
(Base Menu continued)
ENTER Sets MiniCSU-3 access code address
Access Code
0000000
Modify Value up/down
ENTER to accept
ENTER
Date Format
DD/MM/YYYY
Modify Value up/down
ENTER to accept
ENTER
Date 25/12/2005
Time 01:11:11
ENTER
Alarm Report
Off
INC/DEC toggles state
ENTER to accept
ENTER
Daily Report
Off
INC/DEC toggles state
ENTER to accept
(If Daily Rep not = Off) ENTER
Daily Rep Time
15:15
INC/DEC toggles state
ENTER to accept
ENTER
Modem
Off
INC/DEC toggles state
ENTER to accept
(If Modem not = Off) ENTER
Country Code
61
Modify Value up/down
ENTER to accept
ENTER External modem initialisation string
Cust Init String
None
Modify Value up/down
ENTER to accept
ENTER
Phone 1
0398887788
Modify Value up/down
ENTER to accept
ENTER
Phone 1 Cont
2323
Modify Value up/down
ENTER to accept
ENTER
Phone 2
0398887788
Modify Value up/down
ENTER to accept
ENTER
Phone 2 Cont
2323
Modify Value up/down
ENTER to accept
ENTER
Phone 3
0398887788
Modify Value up/down
ENTER to accept
ENTER
Phone 3 Cont
2323
Modify Value up/down
ENTER to accept
ENTER
Audio Alarm
Off
INC/DEC toggles state
ENTER to accept
ENTER Circuit breaker auxiliary contact circuit input configuration
Cct Input
Not Used
INC/DEC toggles state
ENTER to accept
ENTER Battery circuit breaker auxiliary contact circuit input configuration
Batt Switch Input
Not Used
INC/DEC toggles state
ENTER to accept
ENTER
LVDS Input
Not Used
INC/DEC toggles state
ENTER to accept
ENTER ENTER
Auxiliary Units
Press ENTER
1-ph AC Monitor
Off
INC/DEC toggles state
ENTER to accept
(If 1-ph AC Monitor not = Off) ENTER
1ph AC Vhi Alarm
260V
Modify Value up/down
ENTER to accept
ENTER
1ph AC Vlo Alarm
200V
Modify Value up/down
ENTER to accept
ENTER
1ph AC fhi Alarm
55.0Hz
Modify Value up/down
ENTER to accept
ENTER
1ph AC flo Alarm
45.0Hz
Modify Value up/down
ENTER to accept
ENTER
1ph AC FS Curr.
100A
Modify Value up/down
ENTER to accept
Battery low voltage disconnect switch auxiliary circuit input
configuration
ENTER selects hours,
minutes, day, month or year
INC/DEC modifies value

Unipower Sageon Micro Power Module Specifications

Input Power

input voltage	85-300VAC
inrush current	<9A RMS per rectifier
power factor	>0.98 for >50% output power

Output Power

output voltage for -48VDC systems	adjustable range 42.0V to 59.5V
output voltage for +24VDC systems	adjustable range 21.0V to 30.0V
efficiency for 48VDC systems	>90% at 100% output power

Environmental Conditions

operating temperature	-40°C to +70°C
full power temperature range	-40°C to +55°C
storage/transport temperature	-40°C to +70°C

Mechanical Dimensions

width	483mm (19”)
depth	355mm (14”)
height	88mm – 352mm (3.4” – 13.6”) depending on configuration
