Unipower Sageon Micro Power Module User Manual

Operation Sageon Micro Power Module Manual
PM990-4207-00, Rev 6
5-10
(Battery Menu continued)
More detailed explanations of all the menu items are available in the Controller Operation PDF on the Manual CD.
ENTER Enable/disable Equalisation charging
Equalisation
On
ENTER toggles state
Off / On
ENTER Charge current limit for battery voltage
BILim Vb>Vfl
20A
Modify Value up/down
ENTER to accept
between float & equalise
ENTER System Equalise voltage without BTC.
System Equalise
56.5V
Modify Value up/down
ENTER to accept
Sense point voltage regulated to this value
ENTER Enable/disable bus voltage discharge
Volts Start Eq
On
ENTER toggles state
Off / On
triggering of equalisation charging
ENTER Threshold below which Eq is triggered
Volts Eq Trigger
46.0V
Modify Value up/down
ENTER to accept
ENTER Enable/disable battery capacity loss
Q Start Eq
On
ENTER toggles state
Off / On
triggering of equalisation charging
ENTER Threshold below which Eq is triggered
Q Loss Trigger
25Ah
Modify Value up/down
ENTER to accept
ENTER Battery charging current below which
EQ End Current
15A
Modify Value up/down
ENTER to accept
equalisation charging terminates
ENTER Maximum duration of equalisation
EQ Duration
3 hours
Modify Value up/down
ENTER to accept
ENTER Periodic equalisation charging trigger
EQ Period
12 Weeks
Modify Value up/down
ENTER to accept
Set to zero to disable
ENTER Manual control of equalisation
Manual Start Eq
Press ENTER
ENTER toggles state
Start / Stop
ENTER Battery voltage below which the LVDS
LVDS Trip
43.0V
Modify Value up/down
ENTER to accept
opens when in Auto mode.
ENTER LVDS (where used) operation mode.
(↑)
LV
DS Mode
Auto
Modify Value up/down
ENTER to accept
[Auto, Open, or Closed]
DEC ENTER E
nable/disable battery overtemperature
Temp Sen Alarm
On
ENTER toggles state
Off / On
alarm - set to off if no sensor used.
INC ENTER P
eriodic battery discharge test trigger
(↓)
BDT Period
14 Days
Modify Value up/down
ENTER to accept
Set to zero to disable
ENTER Time of day to begin automatic
BDT Time
21:35
Modify Value up/down
ENTER to accept
discharge testing
ENTER Maximum duration of a discharge test
BDT Duration
1h30min
Modify Value up/down
ENTER to accept
ENTER Discharge test current (controlled)
BDT Current
50A
Modify Value up/down
ENTER to accept
Load must be > the value programmed
ENTER Battery voltage below which the BDT
BDT End V
46.5V
Modify Value up/down
ENTER to accept
terminates.
ENTER Battery loss of capacity below which
BDT End Q
150Ah
Modify Value up/down
ENTER to accept
the BDT terminates.
Result of the Last discharge test
Last BDT
Passed

Unipower Sageon Micro Power Module Specifications

Input Power

input voltage	85-300VAC
inrush current	<9A RMS per rectifier
power factor	>0.98 for >50% output power

Output Power

output voltage for -48VDC systems	adjustable range 42.0V to 59.5V
output voltage for +24VDC systems	adjustable range 21.0V to 30.0V
efficiency for 48VDC systems	>90% at 100% output power

Environmental Conditions

operating temperature	-40°C to +70°C
full power temperature range	-40°C to +55°C
storage/transport temperature	-40°C to +70°C

Mechanical Dimensions

width	483mm (19”)
depth	355mm (14”)
height	88mm – 352mm (3.4” – 13.6”) depending on configuration
