Front Matter Sageon Micro Power Module Manual
PM990-4207-00, Rev 6
iii
NAMEPLATE
A UNIPOWER product is identified by a nameplate that includes model number, part number, and serial number
information, as appropriate. Please include this information, shown in italic in the label drawing below, in all
correspondence with UNIPOWER. A sample nameplate is shown below.
225.8001.00
SAGEON POWER MODULE
PART NUMBER: 111-4219-24
INPUT RATING: 208-240VAC, 18A max,
45-55Hz (each rectifier)
OUTPUT RATING: 24V, 400A
SERIAL #: D5S0412345
INITIAL SETTINGS
All equipment is shipped from the factory fully inspected and adjusted. Read the technical reference or product
manual before installing or making any adjustments.

Unipower Sageon Micro Power Module Specifications

Input Power

input voltage	85-300VAC
inrush current	<9A RMS per rectifier
power factor	>0.98 for >50% output power

Output Power

output voltage for -48VDC systems	adjustable range 42.0V to 59.5V
output voltage for +24VDC systems	adjustable range 21.0V to 30.0V
efficiency for 48VDC systems	>90% at 100% output power

Environmental Conditions

operating temperature	-40°C to +70°C
full power temperature range	-40°C to +55°C
storage/transport temperature	-40°C to +70°C

Mechanical Dimensions

width	483mm (19”)
depth	355mm (14”)
height	88mm – 352mm (3.4” – 13.6”) depending on configuration
