UNIS DYNAMIC ORBS - Page 12

Dynamic Orbs GMP Manual
09/26/2023
11
Step 2 Install LOGO marquee to the back board bracket. Utilize screws to secure.
Step 3 Install Marquee to the top of the cabinet. Connect the connectors. Utilize screws to
secure
Name
Cross recess hexagon bolt set
Spec.
M6×30
Qty
3
Name
Cross recess hexagon bolt set
Spec.
M6×20
Qty
8
LOGO marquee
Back board
bracket
Marquee
