Dynamic Orbs GMP Manual
09/26/2023
13
Step 5 Install Side round plastic. Utilize screws to secure.
Step 6 Install Side motor cover plate. Utilize screws to secure.
Finish!
Name
Cross recess screw set
Spec.
M4×12
Qty
9
Name
Flange nut
Spec.
M4
Qty
4
Name
Cross recess screw set
Spec.
M4×16
Qty
4
