Unison Research
Unico Secondo
17
11. TECHNICAL SPECIFICATIONS
Output power: >100W continuous 8
>180W continuous 4
Output stage: symmetrical complementary
double POWER MOSFET
Valves: 2 x ECC83 (12AX7)
Frequency response: flat@10Hz / -0.5dB@100 kHz
Input impedance: 50 kOhm / 47 pF
Damping factor: >50
Feedback factor: 8dB
Power consumption: 400W max
Dimensions (mm): 435 x 430 x 130 mm
Nett weight: Kg. 15
