EP- 45F Paper Folder Operation Manual
21.
1
2
PAPER SEPARATOR
PAPER FEED ROLLER
2
1
14.Change paper feed roller and rubber pad
Open Roller cover, push the roller to right side,
pull the other side of the roller to remove.
※ Change roller Rubber pad
Remove rubber pad Install rubber pad
Raise the back side to remove pad
Install the pad as to the photo above
Make sure paper feed roller and roller pad are properly installed and placed.
