MECHANICAL / ELECTRICAL
Scanning Area: 0.43” (11mm) from bottom of card
Max Card Thickness: 54 mils (.054”, 1.37mm)
Voltage: 5 Volts DC
TTL (Undecoded): 35mA
Power consumption: Decoded: 70mA
Cord: 6’ 0” (1.83m)
Weight: 6.7 oz. (190 grams) with cable
Dimensions: 3.75” L x 1.375” W x 1.1875” H
(95mm L x 35mm W x 30mm H)
ENVIRONMENTAL
-4° to 140° F (-20° to 60° C)Storage:
Temperature: Operating: 32° to 122° F (0° to 50° C)
Humidity: 0% to 95% RH non-condensing
Mechanical shock: 5 foot (1.5m) drop to concrete
DECODER
Symbologies: Codabar, Code 11, Code 32, Code 39 (Standard
and Full ASCII), Code 93, Code 128, Delta Code,
EAN-8, EAN-13, Label Code IV and V, MSI Code,
Plessey Code, Standard 2 of 5, UPC-A, UPC-E
Interfaces:
PS/2, RS232, TTL, USB (see next page for pinouts)
Configuration: Via Scanner Configuration Manager software
(downloadable from www.ute.com)
Data Editing: Almost unlimited (via Scanner Configuration
Manager software - see above)
PERFORMANCE
Scan rate: 2” (50mm) to 30” (750mm) per second
Print Contrast: 0.6 min.
Resolution: 6 mils (.015mm) min.
Sensor: Photo diode
Depth of field: 2mm
Light Source: Visible Light: 660nm LED
Infrared Light: 930nm LED
SPECIFICATIONS
MS146 Manual
30
