9. Then, click Close.
10. You will see a message telling that the
device driver software is installed
successfully.
11. The scanner will beep twice to verify the connection.
*Note:
In this mode, the scanner is recognized by the host as a mouse (pointing device). If your host
fails to find it, please try [Connecting via Human Interface Device (HID) Mode] instead.
Smartphone Connection (Android)
1. Pair with the scanner via [SPP]; see the topic: Connecting via Serial Port Profile (SPP)
Mode.
2. Install Bluetooth Connect.apk, which is available on CD.
Note: Before installation, enable ‘Unknown Sources” in Android
Authority.
3. Enable [BluetoothConnect] in the Language & Keyboard
setting window and choose [BluetoothConnect] as Input
Method.
4. Click [Connect] and you will be able to connect the scanner.
Note: BluetoothConnect needs to be installed only when you have
NO wireless input application on your Android device. Android 2.x
devices can work with MS910 in the SPP mode ONLY. The SPP
mode or/and the HID mode are not definitely compatible with each
version of Android OS, and thus depends on the Android-based
hardware specifications defined by the Android device
manufacturers.
To get the detailed example of SPP setting, refer to Appendix 2.

Unitech MS910 Specifications

General

Type	Handheld bar code reader
Wavelength	625 nm
Sensor type	CCD / CMOS
Scanner type	1D/2D
Read rate (max)	240 reads/s
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), MSI, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	Compact Matrix Code, Data Matrix
Wireless range	10 m
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Certification	CE, FCC ClassB
Product color	Black, Blue
LED indicators	Yes
Housing material	Acrylonitrile butadiene styrene (ABS)
Cables included	USB
Battery voltage	3.7 V
Power consumption	150 mA
Power source type	Battery
Number of reads per charge	5000
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	65 mm
Width	24 mm
Height	18 mm
Weight	24.6 g
