Unitech MS916 User Manual

- 95 -
￭ iOS Soft Keypad
Please follow the steps to set up iOS Soft Keypad.
Main Menu HID KBD Setting iOS Soft Keypad by DblClick [SCAN]
key Enable *
Disable
4.13.3 Data View/Erase Function
Please follow the steps to view / erase data in Batch mode / Auto mode.
1. In Batch Mode 2. In Auto Mode
Main Menu Data & Memory Batch
Data Press trigger key Exit
Erase
View
Main Menu Data & Memory Buffer
Data Press trigger key Exit
Erase
View
4.13.4 Block Delay to BT SPP and USB SPP
Please follow the steps to send block delay to BT SPP and USB SPP.
Main Menu Data & Memory Sending BlkDly
10 ms *
50 ms-
100 ms
500 ms
1 second
3 seconds

Unitech MS916 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	104 reads/s
Linear (1D) barcodes supported	Codabar, Code 128A, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Not supported
Bluetooth version	2.1+EDR
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Certification	CE, FCC, BSMI, VCCI
Keys quantity	3 keys
Product color	White
Internal memory	16 MB
Built-in display	Yes
Housing material	-
Display resolution	128 x 64 pixels
Display technology	OLED
International Protection (IP) code	IP42
Battery capacity	680 mAh
Power source type	Battery
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	95.9 mm
Width	36.9 mm
Height	21.1 mm
Weight	63 g
