Unitech MS916 User Manual

- 4 -
Functionality
Symbologies
1D Code 39, Full ASCII Code 39, Interleave 2 of 5, UPC A/E/E1,
MSI, Codabar, Code 11, EAN8/13, Code 93, Code 128, EAN
128, Code32, GS1 databar Code, Bookland EAN, Discreate 2
of 5, Chinese 2 of 5, ISBT 128, UCC Coupon Extended Code,
Bookland 128
Scan Mode Trigger mode, Pulse mode, Flash mode, Continuous Mode,
Buffer mode
Data Formatting Prefix, Suffix, Code ID, Reformatting Date
Environmental
ESD Protection Functional after 8K Contact and 12K Air
Mechanical Shock 1.5m onto concrete (scanner only)
IP Rate IP42
Operating Temperature 0°C to 50°C
Storage Temperature -30°C to 70°C
Relative Humidity 95% non-condensing
Electrical
Operation Voltage DC 5V
Current Consumption Operation mode: <125mAh,
Standby mode: <39mAh
Battery Type Rechargeable Li-ion battery
Battery Capacity 680 mAh
Battery Charging time Fully charged in about 4 hours
Operating Time 8 hours at condition of 1 scan/5 sec

Unitech MS916 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	104 reads/s
Linear (1D) barcodes supported	Codabar, Code 128A, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Not supported
Bluetooth version	2.1+EDR
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Certification	CE, FCC, BSMI, VCCI
Keys quantity	3 keys
Product color	White
Internal memory	16 MB
Built-in display	Yes
Housing material	-
Display resolution	128 x 64 pixels
Display technology	OLED
International Protection (IP) code	IP42
Battery capacity	680 mAh
Power source type	Battery
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	95.9 mm
Width	36.9 mm
Height	21.1 mm
Weight	63 g
