Unitech MS916 User Manual

- 13 -
Top Menu Sub Menu Level 1 Sub Menu Level 2 Options/Result Default Setting
3.2 Download Lookup
3.3 Exit
4. Exit Return to the previous menu N/A
The Data & Memory of Display Menu Tree below is based on Batch Mode.
Top
Menu
Sub Menu Level 1 Sub Menu Level 2 Options/Result Default Setting
1.View/ Edit Batch
2.Send Batch
3. Erase Batch
4. Free MEM Space Show Free Batch Memory Space 2 MB
5. Data Separator CR/None/TAB/CRLF/LF CR
6. Sending BlkDly
SENDING BlkDelay
500 ms / 100 ms/ 50 ms / 10 ms/ 3 Sec. / 1 Sec.
10 ms
Data &
Memory
7. Date / Time Stamp
Date Stamp
Settings
Disable *
YYYY-MM-DD
YYYY/MM/DD
YYYY.MM.DD
YYYYMMDD
MM-DD-YYYY
MM/DD/YYYY
MM.DD.YYYY
MMDDYYYY
DD-MM-YYYY
DD/MM/YYYY
DD.MM.YYYY
DDMMYYYY
Time Stamp Settings
Disable *
HH:MM:SS
HH:MM:SS AM
HHMMSS
HHMMSSAM
HH:MM
HH:MM AM
HHMM
HHMMAM
Disable

Unitech MS916 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	104 reads/s
Linear (1D) barcodes supported	Codabar, Code 128A, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Not supported
Bluetooth version	2.1+EDR
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Certification	CE, FCC, BSMI, VCCI
Keys quantity	3 keys
Product color	White
Internal memory	16 MB
Built-in display	Yes
Housing material	-
Display resolution	128 x 64 pixels
Display technology	OLED
International Protection (IP) code	IP42
Battery capacity	680 mAh
Power source type	Battery
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	95.9 mm
Width	36.9 mm
Height	21.1 mm
Weight	63 g
