Unitech MS916 User Manual

- 75 -
4.3.2 Wedge mode
In this mode, the data only transmit while the BT is connected
Wedge mode
4.3.3 Batch mode
In this mode, the scanned data will be stored in the memory all the time and
transmit data only when BT is connected by scanned the “send batch” bar
code
Batch mode
4.3.3.1 Send batch
Scan below bar code to send the stored data to host
Send Batch
4.3.3.2 Erase last memory entry
Scan below bar code to erase last scanned data in batch memory
Erase Last Memory Entry

Unitech MS916 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	104 reads/s
Linear (1D) barcodes supported	Codabar, Code 128A, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Not supported
Bluetooth version	2.1+EDR
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Certification	CE, FCC, BSMI, VCCI
Keys quantity	3 keys
Product color	White
Internal memory	16 MB
Built-in display	Yes
Housing material	-
Display resolution	128 x 64 pixels
Display technology	OLED
International Protection (IP) code	IP42
Battery capacity	680 mAh
Power source type	Battery
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	95.9 mm
Width	36.9 mm
Height	21.1 mm
Weight	63 g
