MSR206 Programmer’s Manual UDN PM017-U Rev.C.1
Section 7 – Data format 2003/10/9
Page 14
Total 28 pages
Section 7 Data format
* [Data Block] format:
Start Field R/W Data Field Ending Field
Command code <ESC> s [Card data] ? <FS> <ESC> [Status]
Hex code 1B 73 [Card data] 3F 1C 1B [Status]
* [Card data] format:
* [Status Byte] format:
Status description HEX ASCII
Ok If read, write or command ok 30h 0
Write or read error 31h 1
Command format error 32h 2
Invalid command 34h 4
Error
Invalid card swipe when in write mode 39h 9
* Note:
1. When [Status Byte] equal 39h means card moving error
2. None available and none data tracks will not be transmitted when swipe of card.
For example, when read card with data encoded on track 2 only for MSR206-5, it will transmit data like 1B 73 1B 01
1B 02 [string] 3F 1C, for no data on track 1 so it shown 1B 01 only.
* [Raw Data Block] format:
Start Field R/W Data Field Ending Field
Command code <ESC> s [Raw data] ? <FS> <ESC> [Status]
Hex code 1B 73 [Raw data] 3F 1C 1B [Status]
* [Raw Data] format:
Raw Data
Char Code <ESC>1[L1][string1]<ESC>2[L2][string2]<ESC>3[L3][string3]
Hex Code 1B 01[L1][string1]1B 02[L2][string2]1B 03[L3][string3]
Note:
1. [L1], [L2], [L3] is the length of [string1],[string2],and [string3]
2. None available and none data tracks will not output when swipe of card,
For example, when read card (encoded data on track 2 only) on MSR206-5, it will transmit data like
1B 73 1B 01 00 1B 02 [L2] [string] 3F 1C
* [Raw Data] bit orientation:
Track 1 for 8 BPC
Read
Card Data
Char Code <ESC> 1[string1] <ESC> 2 [string2] <ESC> 3 [string3]
Hex Code 1B 01 [string1] 1B 02 [string2] 1B 03 [string3]
