MSR206 Programmer’s Manual UDN PM017-U Rev.C.1
Section 3 – Technical specifications 2003/10/9
Page 3
Total 28 pages
Section 3 Technical specifications
ITEM SPECIFICATION
Standard ISO7811
Electrical
Current/operating Typical 350mA Max
Consumption
600mA plus for each writing track
Communication Standard RS232 signal voltage levels. Default, 9600 Baud, None Parity, 8 bits
Power supply External switching Power 24V/2.2A regulated
Interconnection
Cable RJ45->DB9, 5 feet
1.shield
2.TXD / MSR206 data transmit
3.RXD / MSR206 data receive
4,6,7,8,9, no connection
Pin Assignment
DB-9
5. circuit ground
Mechanical
Body ABS 94V-0
Swipe Manual, single direction
Outline 210Lx68Wx60H mm
Weight 1.5Kg approx.
Environment
Operation -10ºC to 60ºC
10 to 85% humidity, non condensing
Storage -30ºC to 70ºC
10 to 90% humidity, non condensing
Performance
Track 1&3 210bpi
Read Circuit
Track 2,75 or 210 bpi
Bit per Char 5-7 bit per char.
Read, 5-50 ips (read speed 5-40 ips for track 2 at 210bpi)
Media Speed
Write, 5-30
Read 300-4000 Oe Mag. Card
MSR206-XHC write 2750-4000 Oe Mag. Card
Media Coercivity
MSR206-XHL write 300-4000 Oe Mag. Card
Media Thickness 0.76-1.2mm
Jitter Card Read bit to bit interval <+/-15% card
