 (II) WRITE RAW DATA TO MAGNECTIC CARD
Converting Card Data Information to Hexadecimal for the Binary Write Function
Converting track one ASCll information into HEX
0 1 2 3
B5 0 0 1 1
B3 B2 B1 B0 B4 0 1 0 1
0 0 0 0 0 (sp) 0 @ P
1 0 0 0 1 ! 1 A Q
2 0 0 1 0 “ 2 B R
3 0 0 1 1 # 3 C S
4 0 1 0 0 $ 4 D T
5 0 1 0 1 % 5 E U
6 0 1 1 0 & 6 F V
7 0 1 1 1 ‘ 7 G W
8 1 0 0 0 ( 8 H X
9 1 0 0 1 ) 9 I Y
A 1 0 1 0 * : J Z
B 1 0 1 1 + ; K [
C 1 1 0 0 ` < L \
D 1 1 0 1 , = M ]
E 1 1 1 0 . > N ^
F 1 1 1 1 / ? O _
Converting track two and three ASCll information into HEX
Data p B3 B2 B1 B0
0 1 0 0 0 0
1 0 0 0 0 1
2 0 0 0 1 0
3 1 0 0 1 1
4 0 0 1 0 0
5 1 0 1 0 1
6 1 0 1 1 0
7 0 0 1 1 1
8 0 1 0 0 0
9 1 1 0 0 1
: 1 1 0 1 0
