Unitech PA600 Getting Started

Chapter 1 Getting Started
11
Turning the PA600 on for the First Time
Charge the PA600 for at least 16 hours prior to initial use. Start the PA600, calibrate
the display, learn some basic Stylus usage, and setup the date and time through the
following:
Powering On
1. Start the PA600 by pressing the
Power Button on the front panel.
NOTE: The PA600’s screen ships
with a protective plastic film.
Remove the plastic film by
peeling from one corner to
another. The screen will be
more susceptible to scratch-
ing without the film, but it will
be more legible.
2. The Unitech PA600 welcome
screen appears for a moment fol-
lowed by the Windows Mobile
screen.
FUNC
Ls
ESC ghi jkl mno
wxyz
ENTER
TAB
tuvpqrs
key
OK
abc Rs def
ALPHA
1
4
7
2
5
8
0
3
6
9
.
Power Button

Unitech PA600 Specifications

System Memory

SDRAM memory	64 MB
Flash ROM	128 MB
Flash ROM with WWAN	320 MB

Display

display resolution	240x320 QVGA
display type	Color Transflective TFT
touch screen	Yes

Power

main battery	3.7V 1950mAh Li-Ion Battery Pack
backup battery	One Rechargeable Ni-MH Backup Battery
power source	Main Battery

Operating Environment

operating temperature	32ºF to 122ºF (0ºC to 50ºC)
storage temperature	-4ºF to 140ºF (-20ºC to 60ºC)
relative humidity	5% ~ 95% (non-condensing)

Weight and Dimensions

weight	290g with Battery & Scan Engine
length	149.5 mm
height	26.6 mm
