4.1 Operation Elements
1. LCD
2. Menu keys
3. Measurement function selection dial
4. Input socket for current measurement range 10A
5. Input socket for measurement ranges
6. Mass connection for all measurement ranges
7. Input socket for current measurement ranges mA, µA
33
Operation Elements
ENGLISH
1
2
3
5
674
