AC, AC+DC Voltage
Measurement Range Hexagon 710 Hexagon 720
Accuracy*
20...45 Hz
500,00 mV; 5,0000 V; 50,000 V Not specified ± (1,5% rdg. + 40 D)
500,00 V; 1000,0 V Not specified Not specified
45...300 Hz
500,00 mV ± (0,3% rdg. + 20 D)
5,0000 V; 50,000 V ± (0,8% rdg. + 60 D) ± (0,8% rdg. + 20 D)
500,00 V; 1000,0 V ± (0,4% rdg. + 40 D)
300 Hz...1 kHz 300 Hz...5 kHz
500,00 mV ± (0,8% rdg. + 40 D) ± (0,3% rdg.+ 40 D)
5,0000 V; 50,000 V; 500,00 V ± (2,0% rdg. + 60 D) ± (0,4% rdg. + 40 D)
1000,0 V ± (1,0% rdg. + 40 D) ± (0,8% rdg. + 40 D)
1 kHz...20 kHz 5 kHz...20 kHz
500,00 mV 1 dB** ± (0,5% rdg. + 20 D)
5,0000 V; 50,000 V 2 dB** ± (0,8% rdg. + 20 D)
500,00 V 3 dB** ± (0,5% rdg. + 20 D)
1000,0 V not specified not specified
20 kHz 100 kHz
500,00 mV ± (2,0 % rdg. + 40 D)
5,0000 V; 50,000 V not specified ±(4,0%rdg.+40 D)**
500,00 V not specified
1000,0 V
* specified for 5% to 10% of measurement range ± (% rdg. + 80 D)
** specified for 5% to 10% of measurement range ± (% rdg. + 180 D), for 5%
to 10% of measurement range ± (% rdg. + 100 D)
Overload protection: 1050 Vrms, 1450 Vss
CMRR: >90 dB(0...60 Hz, Rs= 1kOhm)
Input impedance: 10 MOhm, 30 pF nominal (80 pF nominal within 500 mV
measurement range)
71
Technical Data
ENGLISH
