Unitree A1 PRO - Appendix; Specifications; Interface Diagram

A1 PRO User Manual
Copyright © 2020 Unitree Robotics. All Rights Reserved 49
Appendix
Specifications
Visit Unitree official website.
Chinese：http://www.unitree.cc/cn/
English：http://www.unitree.cc/
Interface diagram
⑬
⑪
⑫
1. TX2 HDMI
2. TX2 USB3.0
3. TX2 USB2.0
4. Ethernet Interface 1
5. Power Input 24V
6. Power Input 24V
7. Power Output (5V，2A)
8. Power Output (12V，2A)
9. Power Output (19V，2A)
10. Ethernet Interface 2
11. MiniPC USB2.0
12. MiniPC USB3.0
13. MiniPC HDMI
