Apollo Hardware Manual Specifications
30
Hi–Z Inputs
Jack Type
¼” Male (Mono TS plug required)
Dynamic Range
117 dB (A–weighting)
Signal-to-Noise Ratio
117 dB (A–weighting)
Total Harmonic Distortion + Noise
–103 dB
Input Impedance
2.2 Megohms
Gain Range
+10 dB to +65 dB
Maximum Input Level (Minimum Gain)
10 dBV
Maximum Input Level (Maximum Gain)
–45 dBV
Line Inputs 1 – 4
Jack Type
¼”Male TRS Balanced
Dynamic Range
117 dB (A–weighting)
Signal-to-Noise Ratio
117 dB (A–weighting)
Total Harmonic Distortion + Noise
–107 dB
Common-Mode Rejection Ratio
>60 dB (10’ cable)
Stereo Level Balance
±0.05 dB
Input Impedance
10 Kilohms
Gain Range
+10 dB to +65 dB
Maximum Input Level (Min Gain)
18 dBV
Maximum Input Level (Max Gain)
–37 dBV
Line Inputs 5 – 8
Jack Type
¼” Male TRS Balanced
Dynamic Range
117 dB (A–weighting)
Signal-to-Noise Ratio
117 dB (A–weighting)
Total Harmonic Distortion + Noise
–107 dB
Common-Mode Rejection Ratio
>60 dB (10’ cable)
Stereo Level Balance
±0.05 dB
Input Impedance
10 Kilohms
Gain Settings
+4 dBu / –10 dBV (selectable)
Maximum Input Level (+4 dBu)
18 dBV
Maximum Input Level (–10 dBV)
–6 dBV
Line Outputs 1 – 8
Jack Type
¼” Male TRS Balanced
Dynamic Range
118 dB (A–weighting)
Frequency Response
20 Hz – 20 kHz, ±0.1 dB
Signal-to-Noise Ratio
118 dB (A–weighting)
Total Harmonic Distortion + Noise
–106 dB
Stereo Level Balance
±0.05 dB
Channel Separation
>120 dB
Output Impedance
600 Ohms
Maximum Output Level
18 dBV
(continued)
