Universal L60 - Page 32

Bill of Material
ITEM NUM: PART NUMBER: PART DESCRIPTION: QTY:
L60 LABEL APPLICATOR
L60
01
(
D
)
L60-I-60D
A
SSEMBLY, GUIDE 1
02
(
D
)
L60-I-30D
A
SSEMBLY, TAMP 1
02
(
D
)
L60-I-31D
A
SSEMBLY, BLOW 1
03
(
E
)
VH-L60
A
SSEMBLY, L-60 VACUUM HEAD 1
04 L-128-C CLIP,
(
4-1/2 WEB
)
RETENTION 1
04
(
B
)
L-128-C-
A
CLIP,
(
6-1/2 WEB
)
RETENTION 1
05 L-128-D SPOOL,
(
4-1/2 WEB
)
REWIND 1
05
(
B
)
L-128-D-
A
SPOOL,
(
6-1/2 WEB
)
REWIND 1
06 L-137-D ROLL, DRIVE 1
07
(
D
)
L60-I-10D
A
SSEMBLY, FRONT SIDE PANEL 1
08
(
D
)
UWA-13R-I-00
A
SSEMBLY, R. H. 13" UNWIND 1
08
(
A
)(
D
)
UWA-13L-I-00
A
SSEMBLY, L. H. 13" UNWIND 1
09 100234 FTNG, EXHAUST MUFFLER 2
10 L60-0018
A
PANEL, BACK 1
11 L-154-C-02 COVER, TOP REAR SS 1
12 L-153-C-02 COVER, TOP CENTER SS 1
13 L-152-C-02 COVER, TOP FRONT SS 1
14 L-108-T1 BAR, REAR ACCESSORY MOUNTING 1
15 L60-1014 SPACER, MOUNT 2
16 L60-1013 MOUNT, 4 STATION BASE 1
17
(
D
)
L60-I-70D
A
SSEMBLY, VALVE 1
18 SC-006 COLLAR, SET .376 X .62 X .250 3
19 L-139-P-2 SHAFT, REWIND 1
20 200255 STRIP, 12 TERMINAL EURO 1
21 L-172-01 WASHER, ALUM. 062 x 375 x 625 2
22 L-212 BLOCK, INBOARD REWIND BEARING 1
23 L-172-02 WASHER, UHMW 031 X 375 X 625 1
24 L-140-F-3 COLLAR, REWIND SLIP 1
25 L60-0028 SHAFT,
(
4-1/2 WEB
)
DRIVE 1
25
(
B
)
L60-0028-W SHAFT,
(
6-1/2 WEB
)
DRIVE 1
26 L-108-T BAR, ACCESSORY MOUNTING 1
27
(
D
)
L60-I-20D
A
SSEMBLY, REAR SIDE PANEL 1
27
(
D
)
L60-I-20D1
A
SSEMBLY, REAR SIDE PANEL 1
28 L-155-C-02 COVER, BOTTOM SS 1
29 L-114-T BAR, LOWER REAR TIE 1
30 L-113-T BAR, LOWER FRONT TIE 1
31
(
D
)
L60-I-40D
A
SSEMBLY, GUAGE 1
32
(
D
)
L60-I-50D
A
SSEMBLY, FRONT PANEL 1
32
(
C
)(
D
)
L60-I-51D
A
SSEMBLY, FRONT PANEL
(
PLC
)
1
(A) = Left Hand Machine
(B) = Wide Label
(C) = PLC Models
(D) = See Drawing
(E) = Custom, Per Label Size
F:\LABELERS\L-60\MANUAL\L60-I-00D.dwg
