UN-PACKING INSTRUCTIONS
When the machine is received, the shipping carton will contain the following items.
Fig 2
1. L-60 Body.
2. Unwind assembly.
3. Unwind assembly-backing plate.
4. Unwind assembly label roll retainer.
5. Air Fitting Part #100373 ¼ NPT x 3/8.
6. 10’ of 3/8” hose.
7. Product switch in a padded envelope.
8. This manual in manila envelope.
Extended peeler bar assembly (OPTIONAL). See notes below. **
**When the machine is ordered with an extended peeler bar assembly, it will be
packed disassembled from the machine body.
Remove the machine body by placing your hands under the bottom for lifting. Refer
to the packing list, and check all packing materials to insure all of the machine parts
and accessories are accounted for.
