Universal L60 - Page 34

Bill of Material
ITEM NUM: PART NUMBER: PART DESCRIPTION: QTY:
ASSEMBLY
,
FRONT SIDE PANEL
L60
01 SC-006 COLLAR, SET .376 X .62 X .250 6
02 L-172-02 WASHER, UHMW 031 X 375 X 625 4
03 L60-0036 ROLL,
(
4-1/2 WEB
)
UPPER IDLER 2
03
(
A
)
L60-0037 ROLL,
(
6-1/2 WEB
)
UPPER IDLER 2
04 L-121-D STUD,
(
4-1/2 WEB
)
STAND OFF 1
04
(
A
)
L-121-D-1 STUD,
(
6-1/2 WEB
)
STAND OFF 1
05 L-143 ROLLER, 3" LOWER IDLER
(
ALUM.
)
1
05
(
A
)
L-143-1 ROLLER, 6" LOWER IDLER
(
ALUM.
)
1
06 L60-0093 PANEL, FRONT SIDE 1
06
(
D
)
L60-0093S PANEL, STAINLESS FRONT SIDE 1
07 L60-0008 BAR, COVER SUPPORT 1
08 L60-0007R
A
SS'Y,
(
4-1/2 WEB
)
RH IDLER 1
08
(
A
)
L60-0007RW
A
SS'Y,
(
6-1/2 WEB
)
RH IDLER 1
08
(
B
)
L60-0007L
A
SS'Y,
(
4-1/2 WEB
)
LH IDLER 1
08
(
C
)
L60-0007LW
A
SS'Y,
(
6-1/2 WEB
)
LH IDLER 1
09 L60-0008A BAR, COVER SUPPORT 1
10 L-167 BLOCK, COMP SPRING RETAINING 1
11 L-165 FOLLOWER, SPRING 1
12 420185 SPRING,.42X1-1/2 COMP MW 1
13 L-104-FR
A
SS'Y, RIGHT PIVOT ARM 1
13
(
B
)
L-104-FL
A
SS'Y, LEFT PIVOT ARM 1
14 L-172-03 WASHER, UHMW 062 X 380 X 625 1
15 L-172-04 WASHER, UHMW 125 X 380 X 625 1
16 856002 RING, 3/8" EXT. RETAINING 1
17
(
F
)
SC-006 COLLAR, SET .376 X .62 X .250 2
18
(
F
)
L60-0028 SHAFT,
(
4-1/2 WEB
)
DRIVE 1
18
(
A
)(
F
)
L60-0028-W SHAFT,
(
6-1/2 WEB
)
DRIVE 1
19 L-162 SUPPORT, TOP COVER 1
20 200009 RELAY, 12VDC 10AMP DPDT 1
21 200011 SOCKET, 10 AMP RELAY 1
22 MD-722 BRACKET, RELAY 1
23 200028 CONNECTOR, MALE 9 PIN MOLEX 1
23
(
E
)
200148 CONNECTOR, MALE 12 PIN MOLEX 1
24 L-151-M-R BRACKET, RIGHT MOLEX CONNECTOR 1
24
(
B
)
L-151-M-L BRACKET, LEFT MOLEX CONNECTOR 1
24
(
E
)
SL1-005 BRACKET, MOLEX CONNECTOR 1
25 L-133-P STUD, PIVOT ARM 1
26 L-144-M-1 BLOCK, WITH BEARING 1
27 L-123-M BRACKET, UNWIND MOUNTING 1
28
(
F
)
L-139-P-2 SHAFT, REWIND 1
(A) = Wide Label
(B) = Left Hand Machine
(C) = Left Hand Wide Label
(D) = Stainless Steel Machine
(E) = PLC Models
(F) = Reference Only
F:\LABELERS\L-60\MANUAL\L60-I-10D.dwg
