Universal L60 - Page 38

Bill of Material
ITEM NUM: PART NUMBER: PART DESCRIPTION: QTY:
ASSEMBLY, REAR SIDE
L60
01
(
D
)
L-140-F-3 COLLAR, REWIND SLIP 1
02 SL1-023
A
SS'Y, REWIND HUB 1
03 400010 RETAINER, 3/8" HARDENED BRNG. 2
04 400009 BEARING, 3/8" THRUST 1
05 420170 SPRING, .54 X 1.5 COMP. S.STL 1
06 L-140-F RETAINER, SLIP CLUTCH SPRING 1
07 L-140-F-1 BLOCK, SLIP CLUTCH RETAINER 1
08 100345 FTNG, SWVL EL 1/8 X 1/4" 9
09 100300 REGULATOR, AIR 2
10 100299 FTNG, 1/8" NPT BLACK PLUG 6
11
(
D
)
L60-0028 SHAFT,
(
4-1/2 WEB
)
DRIVE 1
11
(
A
)(
D
)
L60-0028-W SHAFT,
(
6-1/2 WEB
)
DRIVE 1
12 210065 RELIEF, BANNER STRAIN 1
13 300066-TEMP MOTOR 1
14 L60-0029B PULLEY, DRIVE 1
15 600184 BELT, TIMING 1
16 L60-0089 ROLLER, IDLER 1
17 L60-0008 BAR, COVER SUPPORT 2
18 L-172-16 WASHER, UHMW 063 X 505 X 750 3
19 SC-007-1 COLLAR, SET .501 X .75 X .297 1
20 L60-0088 MANIFOLD, AIR 1
21 100373 FTNG, STRT 1/4 X 3/8 2
22 400165 PULLEY, 30XLB037 TIMING 1
23 SC-006 COLLAR, SET .376 X .62 X .250 1
24 L-144-M-1 BLOCK, WITH BEARING 1
25 SL1-019 STUD, MOTOR STAND-OFF 3
26
(
B
)
SL1-I-20
A
SSY. BELT TENSIONER 1
27 100250 FILTER, VACUUM WITH 1/4" FTGS 1
28 100251 ELEMENT, FILTER
(
REPLACEMENT
)
1
29 210118 RESISTOR, KIT 1
30 L60-0095 PLATE, CAPACITOR/RESISTOR MNT. 1
31 L60-0094 PANEL, REAR SIDE 1
31
(
C
)
L60-0094S PANEL, STAINLESS REAR SIDE 1
32 100125 VACUUM EJECTOR W/1/4" PORTS 1
33 L-162 SUPPORT, TOP COVER 1
34 200032C
A
SS'Y, PRODUCT SWITCH 1
35 200015
A
MPHENOL, 4 PIN FEMALE 1
36 200019
A
MPHENOL, 6 PIN
(
FEMALE
)
1
37 UNIV-02 PLATE, UNIVERSAL SERIAL NUMBER 1
38 100321 NUT, PANEL MOUNT AIR REGULATOR 2
39 100415-120
A
IRLINE, 3/8" X 10'CLEAR 1
40 100211 FTNG, 1/8 TO 1/4 STRT CONN. 1
41 210119 CAPACITOR 1
42 100250-1 MOUNT, FILTER 1
(A) = Wide Label
(B) = See Drawing
(C) = Stainless Steel Machine
(D) = Reference Only
