Bill of Material
ITEM NUM: PART NUMBER: PART DESCRIPTION: QTY:
ASSEMBLY
BELT TENSIONER
L60
01 430140 BUSHING, 313 X 250 X 750 1
02 L-132-P-2 PIN, IDLER ROLL 1
03 L-132-P-1 BRACKET, IDLER ASSY 1
04 856001 RING, 1/4" EXT. RETAINING 1
05 L-172-09 WASHER, UHMW 032 X 257 X 500 1
06 400015 BEARING, 1/4" ROLLER 2
F:\LABELERS\SL-1000\MANUAL\SL1-I-20.dwg
