Universal L60 - Page 44

Bill of Material
ITEM NUM: PART NUMBER: PART DESCRIPTION: QTY:
ASSEMBLY, BLOW
L60
01 SS-115 GUSSET, SUPPORT 1
02 L60-0036 ROLL,
(
4-1/2 WEB
)
UPPER IDLER 1
02
(
B
)
L60-0037 ROLL,
(
6-1/2 WEB
)
UPPER IDLER 1
03 L-172-02 WASHER, UHMW 031 X 375 X 625 2
04 850041T THUMBSCREW, 8-32 X 5/8" 1
05 L60-0010 PLATE, SIDE RAIL PEELER 1
06 MP-2500-9 PLATE, WEB DRAG PRESSURE 1
07 L60-0035 BLOCK, WEB DRAG 1
08 L60-0011 SHAFT, WEB DRAG 1
08
(
B
)
L60-0011-W SHAFT, WEB DRAG 1
09 L-150-2-
A
BAR,
(
4-1/2 WEB
)
PEELER TIE 1
09
(
B
)
L-150-2-B BAR,
(
6-1/2 WEB
)
PEELER TIE 1
10 L60-0003
A
BRACKET, AIR CYLINDER MOUNTING 1
10
(
B
)
L60-0003W BRACKET,
(
6-1/2" WEB
)
AIR CYL. 1
11 L60-0003B BRACKET, AIR CYLINDER ADJUST 1
12 L-105-D
A
A
SS'Y, WEB GUIDE CLAMP 2
13 L60-0019 PLATE, RH
(
4-1/2 WEB
)
PEELER 1
13
(
B
)
L60-0019-W PLATE, RH
(
6-1/2 WEB
)
PEELER 1
13
(
A
)
L60-0020 PLATE, LH
(
4-1/2 WEB
)
PEELER 1
13
(
C
)
L60-0020-W PLATE, LH
(
6-1/2 WEB
)
PEELER 1
14
(
D
)
VH-L60-B
A
SS'Y, BLOW VACUUM HEAD 1
15 L60-0061B PLATE, VACUUM HEAD MOUNTING 1
16 L60-0060 BRACKET, AIR CYLINDER ADJUST 1
17 400098 WASHER,1/2 FLAT S.S. 1
18 L60-0054 BRACKET, BLOW TUBE MNT 1
19 L60-0014 TUBE, 5" AIR ASSIST 1
19
(
B
)
L60-0014-W TUBE, 7" AIR ASSIST 1
20 L60-0054 BRACKET, BLOW TUBE MNT 1
21 100326 VALVE, METER-IN 1/4" X 10-32 1
22 600300-4.50 UHMW, TAPE, 1" x 4-1/2" 1
22
(
B
)
600300-6.75 UHMW, TAPE, 1" x 6-3/4" 1
23 L60-0009 PLATE, SWING 1
(A) = Left Hand Machine
(B) = Wide Label
(C) = Left Hand Wide Label
(D) = Custom, Per Label Size
F:\LABELERS\L-60\MANUAL\L60-I-31D
MSACCESS X:\SALES\BOM
