Bill of Material
ITEM NUM: PART NUMBER: PART DESCRIPTION: QTY:
ASSEMBLY, FRONT PANEL
L60
01
(
C
)
200216C
A
SS'Y, CYLINDER DWELL TIME 1
02
(
C
)
200216B
A
SS'Y, TIME DELAY ON / OFF 1
03 200057 VARISTOR 1
04 L-100-R2 PANEL, R.H. FRONT 1
04
(
A
)
L-100-L2 PANEL, L.H. FRONT 1
05 200006 SWITCH, DPST ROCKER
(
MAIN
)
1
06 210067 PLUG, 5/16 HOLE 1
07
(
C
)
200192 DIAL, 10 TURN POT 3
08 200035 RELIEF, 1/8" STRAIN 1
09 200005 HOLDER, PANEL MOUNT FUSE 1
10 200042 FUSE, AGC 3 A 1
11 200036 CORD, 18/3 8FT. SJT POWER 1
11
(
B
)
200279
A
A
SSY. CONVEYOR POWER CABLE 1
12 200013
A
MPHENOL, 3 PIN
(
FEMALE
)
2
13 200017
A
MPHENOL, 5 PIN
(
FEMALE
)
1
14 200007 SWITCH, SPST ROCKER
(
MOTOR
)
1
15 200029 CONNECTOR, FEMALE 9 PIN MOLEX 1
16 200160 TRANSFORMER, 12-VOLT 1
17 600345
A
RUBBER, CIRCUIT CARD BACKING 1
18 L-181-B BRACKET, EDGE CARD 1
19 200022 CONNECTOR, 15 PIN EDGE 1
20 200198 MODULE, POWER 1
21 200023 CLAMP, 1/4" CABLE-AMBER 2
(A) = Left Hand Machine
(B) = Machine on Conveyor
(C) = Optional
