Universal L60 - Page 50

Bill of Material
ITEM NUM: PART NUMBER: PART DESCRIPTION: QTY:
ASSEMBLY, FRONT PANEL (PLC)
L60
01 209021-1 CLIP, RELAY SOCKET 2
02 100541 SUPPLY, 120Vac TO 24Vdc POWER 1
03 240261 PLC, 14I/0 RELAY
(
AROMAT
)
1
04 209020 RELAY, 24VDC 10AMP DPDT 1
05 200228 DIODE 1
06 209021 SOCKET, RELAY 1
07 200314 STOP, DIN RAIL
(
WAGO
)
4
08 200308-4.375 RAIL, 4-3/8" DIN 1
09 L60-0072 PLATE, PLC MOUNTING 1
10 200061 CLAMP, 1/8 CABLE 1
11 200025 CLAMP, 3/8" CABLE-AMBER 1
12 200149 CONNECTOR, FEMALE 12 PIN MOLEX 1
13 200007 SWITCH, SPST ROCKER
(
MOTOR
)
1
14 200013
A
MPHENOL, 3 PIN
(
FEMALE
)
3
15 200057 VARISTOR 1
16 L-100-R2 PANEL, R.H. FRONT 1
16
(
A
)
L-100-L2 PANEL, L.H. FRONT 1
17 200006 SWITCH, DPST ROCKER
(
MAIN
)
1
18 210067 PLUG, 5/16 HOLE 1
19 700050 PLUG, 3/8 HOLE 3
20 200035 RELIEF, 1/8" STRAIN 1
21 200005 HOLDER, PANEL MOUNT FUSE 1
22 200042 FUSE, AGC 3 A 1
23 200036 CORD, 18/3 8FT. SJT POWER 1
23
(
B
)
200279
A
A
SSY. CONVEYOR POWER CABLE 1
(A) = Left Hand Machine
(B) = Machine on Conveyor
