Universal L60 - Page 52

Bill of Material
ITEM NUM: PART NUMBER: PART DESCRIPTION: QTY:
ASSEMBLY
,
GUIDE
L60
01 L-168-A COVER, RIGHT STAR WHEEL 1
01
(
A
)
L-168-B COVER, LEFT STAR WHEEL 1
02 430165 BUSHING, 375 X 250 X 750 1
03 L-109-S-3 PIN, STARWHEEL PIVOT ARM 1
04 L-170 PIN, STARWHEEL PIVOT ARM ASSY. 1
05 L-129-S-1 WHEEL, STAR 1
06 200109 SWITCH, MICRO 1
07 L-164 SPACER, MICRO SWITCH 1
08 L-109-S-2
A
RM, STARWHEEL PIVOT 1
09 L-105-L
A
A
SSY. L.H. WEB GUIDE CLAMP 1
10 L-105-RA
A
SSY. R.H. WEB GUIDE CLAMP 1
11 L-107-D-1 BRACKET, CHANNEL 1
11
(
B
)
L-107-D-3-R BRACKET, CHANNEL
(
RIGHT
)
1
11
(
C
)
L-107-D-3-L BRACKET, CHANNEL
(
LEFT
)
1
12 200016
A
MPHENOL, 4 PIN
(
MALE
)
1
13 853003 WASHER, 1/4" .050 THK 5/8 ODFW 2
14 L-205 STAND-OFF, STARWHEEL ADJUST 2
15 850007T THUMBSCREW, 1/4-28 X 2-1/4" 2
16 L-107-D-2 PLATE,
(
4-1/2" WEB
)
GUIDE SUP. 1
16
(
B
)
L-107-D-2-
A
PLATE,
(
6-1/2" WEB
)
GUIDE SUP. 1
17 L60-0016 BRACKET, LABEL SENSE MOUNTING 1
17
(
B
)
L60-0016-W BRACKET, W.L. SENSE MOUNTING 1
18 856109 PIN, 3/32 X 1 ROLL 1
19 420173 SPRING, 3/16 X 1-1/4 EXTENS SS 1
(A) = Left Hand Machine
(B) = Wide Label
(C) = Left Hand Wide Label
F:\LABELERS\L-60\MANUAL\L60-I-60D.dwg
