Bill of Material
ITEM NUM: PART NUMBER: PART DESCRIPTION: QTY:
ASSEMBLY
R. H. 13" UNWIND
L60
01 UND-001 BAR, LABEL REEL MOUNTING 1
02 UND-002 SHAFT, UNWIND 1
03 UND-003
RM, UNWIND BRAKE 1
04 UND-004 SHAFT, BRAKE ARM 1
05 UND-006 BLOCK, BELT FASTENER 1
06 UND-007 CLAMP, BELT 2
07 UND-008 STUD, BRAKE ARM 1
08 UND-009-1 STRAP, BRAKE 1
09 UND-011C HUB, MAIN UNWIND 1
10 UND-013 DISC, REMOVABLE LABEL 1
11 UND-015 DISC, UNWIND BACKING 1
12 UND-038 ROLLER, BRAKE IDLER 1
13 UND-037 BEARING, BRAKE ARM ROLLER 2
14 UND-019 CLAMP, INNER BACKING DISC 1
15 200409 CLIP, CORE
FOR HUB
4
16 UND-042 CLAMP, OUTER BACKING DISC 1
17 UND-027 BEARING, END CAP ROLLER 1
18 430306 BUSHING, 750 X 500 X 625" 1
19 420210 SPRING, 1/2 X 3.125" EXTENSION 1
20 UND-046 BEARING, END CAP ROLLER 1
21 820000 THUMBSCREW, 1" BLACK NYLON 1
22 400059 BEARING, 5/8" THRUST W/WASHERS 1
23 856005 RING, 1/2" EXT. RETAINING 1
24 853003 WASHER, 1/4" .050 THK 5/8 ODFW 1
25 851002 SCREW, 1/4-20 X 1/2" HHMS 1
26 853001 WASHER, 5/16" FW SS 1
27 851003 SCREW, 5/16-18 X 1/2" HHMS SS 1
28 852001 SCREW, 10-32 X 1/2" FHMS PHIL 6
29 850001 SCREW, 1/4-20 X 1" L SHCS 1
30 850002 SCREW, 10-32 X 1" L SHCS 2
31 854001 NUT, 10-32 HEX 2
32 850003 SCREW, 5/16-18 X 1-1/4" L SHCS 1
33 850006 SCREW, 6-32 X 5/8" L SHCS 2
34 850004 SCREW, 5/16-18 X 1" L SHCS 1
35 852501 SCREW, 4-40 X 1/4" L PHMS PHIL 4
36 854007 NUT, 4-40 HEX SS 4
F:\ACCESSORIES\UND\MANUAL\UWA-13R-I-00.dwg
