Bill of Material
ITEM NUM: PART NUMBER: PART DESCRIPTION: QTY:
ASSEMBLY
,
LION EYE OPTICAL LABEL SENSOR
L60
01 210077 SENSOR, CLEAR LABEL 1
02 OLS-029 BRACKET, LION MOUNTING 1
03 L-172-03 WASHER, UHMW 062 X 380 X 625 1
04 700015 GUIDE, 1" SPLIT NYLON WEB 2
05 OLS-005-1 SHAFT, SENSOR BRACKET 1
05
(
A
)
OLS-005-5 SHAFT, SENSOR BRACKET 1
06 OLS-023 ROLLER, LOWER IDLER 1
06
(
A
)
OLS-023
A
ROLLER, LOWER IDLER 1
07 L60-0035 BLOCK, WEB DRAG 1
08 OLS-024 PLATE, WEB DRAG PRESSURE 1
09 L-172-02 WASHER, UHMW 031 X 375 X 625 1
10 OLS-021 SHAFT, PINCH ROLLER 1
10
(
A
)
OLS-021
A
SHAFT, PINCH ROLLER 1
11 L60-0011 SHAFT, WEB DRAG 1
11
(
A
)
OLS-006 STUD, WEB DRAG STAND-OFF 1
12 OLS-007-1 BRACKET, SLIDE 1
13 OLS-009
A
BRACKET, WEB SUPPORT 1
14 OLS-008 BRACKET, MOUNTING 1
15 OLS-003 SHAFT, MAIN SUPPORT W/ FLAT 1
16 OLS-004 SHAFT, MAIN SUPPORT 1
17 OLS-015 BUSHING, 500 X 375 HEX. X 1.12 2
18 500081 HANDLE, 10-32 MALE RATCHET 2
(A) = Wide Label
