Uplink 4530 - Installation; General Considerations; DIP Switch Settings

4G PRIMARY
ALARM COMMUNICATOR
12
INSTALLATION
A. General Considerations
Determine where to mount the unit. Keep the following in mind:
a. Where to obtain the best transmitted and received signal strength for the
cellular radio. (If the installer does not have a very strong cellular signal
inhisarea,hemaywanttorstpowertheunitfromaportable12VDC
source, switch on S4 and move the unit to a location that gives him the
best signal strength.)
b. Proximity to the alarm panel and where to route the 4530’s relay output
that connects to an alarm panel input.
B. DIP Switch Settings
The 4530 has a four-position dipswitch. The dipswitches function as follows:
SWITCH NO. SETTING FUNCTION
S1: Default Load OFF Normal Operations
ON Load Defaults
S2: OTA Operation OFF OTAcongurationallowed
ON OTAcongurationblocked
S3: Reserved OFF N/A
ON N/A
S4: LED Function OFF Normal Operations
ON RSSI Measurements
(INSTALLATION continued next page)
