4530
27
APPENDIx B:
4530 DEFAULT EvENT CODES
The 4530 is defaulted to send both the Alarm/Trouble condition and the Restoral
condition for all of the events listed below. Reporting of individual events can be
controlled from the Dealer Website.
Following is a list of the default event codes sent by the 4530:
EvENT DESCRIPTION CONTACT
ID EvENT
CODE
SIA DC-03
EvENT
CODE
MODEM
IIe/IIIa/
llla
2
ZONE NO.
REPORTED
Low DC Voltage E302 YT 4B 240
Low DC Restoral R302 YR 4C 240
Cable Supervision Trouble E616 YX 11 242
Cable Supervision Restoral R616 YZ 12 242
Cellular Service Loss E355 YC 11 243
Cellular Service Restoral R355 YK 12 243
4530 UNIT DISABLED E616 YX 11 245
4530 UNIT RESTORAL R616 YZ 12 245
WATCHDOG CIRCUIT
TROUBLE
E616 YX 11 246
Watchdog Circuit Restoral R616 YZ 12 246
Test E602 TX 33 000
