Upright SB60 - JIB BOOM ASSEMBLY

Illustrated Parts Breakdown
Section
SB60 Work Platform6-18
6.2
JIB BOOM ASSEMBLY
100011-000
ITEM PART DESCRIPTION QTY.
1 100456-000 UPPER JIB BOOM WELDMENT 1
2 100458-000 WELDMENT, JIB BOOM, LOWER 1
3 100550-000 HYDRAULIC ROTARY ACTUATOR 1
* 100550-010 SEAL KIT 1
* 100550-011 BEARING KIT 1
4 100551-000 CYLINDER 3 BORE X 23.1 STROKE 1
* 100551-010 SEAL KIT 1
5 100454-001 ROTATOR FRAME WELDMENT 1
6 100472-007 PIN WELDMENT 4
7 100472-008 PIN WELDMENT 1
8 100484-000 PIN WELDMENT, ROTATOR 1
9 011240-012 WASHER, 0-3/4" FLAT 1
10 011248-012 LOCKNUT, 3/4-10 UNC ESNA 1
11 011254-004 SCR, HHC 3/8-16 UNC X 1/2 8
12 011238-006 LOCKWASHER, 0-3/8 SPLIT RING 8
13 011256-010 SCR, HHC 1/2-13 UNC X 1-1/4 6
14 100562-150 BEARING 8
15 100459-000 JIB MOUNTING 1
16 100472-006 PIN WELDMENT 1
17 100688-000 RETAINER, JIB MOUNT PIN 1
18 011254-036 SCR, HHC 3/8-16 UNC X 4-1/2 1
19 011248-006 LOCKNUT, 3/8-16 UNC SENA 2
20 100480-000 PIN, ROD 1
21 011238-008 LOCKWASHER, 0-1/2 SPLIT RING 6
22 011934-001 FITTING, 90° ADAPTER 4MBX-4MJ 2
23 011941-001 FITTING, STR. ADAPTOR 4MB-4MJ 4
24 100283-001 VALVE BLOCK SH 9S002011-A 1
25 014996-006 WASHER, 3/8" FLAT 4
26 011254-028 SCREW, HHC 3/8-16 UNC X 3-1/2 1
28 012004-006 PLUG, HOLLOW HEX #6 SAE 1
29 011252-006 SCREW, HHC 1/4-20 UNC X 3/4 4
30 011238-004 LOCKWASHER, 1/4" DIA. 5
33 011248-004 LOCKNUT, 1/4-20 UNC ESNA 6
34 063497-001 MERCURY SWITCH 1
35 013919-013 CLAMP 1
36 008942-001 COVER, RECEPTACLE 1
37 029961-002 PLUG, INLET FEMALE 1
38 029961-001 SEAL 1
39 011715-006 SCREW, RD. HD. #6-32 X 3/4 4
40 011248-047 LOCKNUT, HEX #6-32 ESNA 4
41 100692-000 COVER, JIB BOOM 1
42 011240-004 WASHER 1/4 FLAT 5
44 061692-099 3/16 GROMMET FT 1.5
45 013919-012 CLAMP HOSE KMC COV 2113 3
46 100551-005 TUBE 1
47 100269-002 VALVE ASSEMBLY 1
48 014252-004 NUTSERT 1/4-20 UNC 2
49 011252-014 SCREW HHC 1/4-20 X 1-3/4 LG 2
50 100490-001 SHIM .062 MC #3088A-476 2
51 100490-002 SHIM .125 MC #3088A-521 2
