Upright SB60 - FRONT AXLE ASSEMBLY

Illustrated Parts Breakdown
Section
SB60 Work Platform6-20
6.2
FRONT AXLE ASSEMBLY
100060-000
ITEM PART DESCRIPTION QTY.
1 100061-000 STEER AXLE WELDMENT 1
2 100064-001 KNUCKLE-RH STEER 1
3 100069-001 KNUCKLE-LH STEER 1
4 100080-000 LINK-STEERING 2
5 100086-000 WELDMENT, KING PIN 4
6 100476-000 WELDMENT-PIN-STEER LINK 4
7 100557-000 STEER CYLINDER 1
* 100557-010 SEAL KIT 1
8 100562-200 BEARING 2.0 ID GAR-MAX GM3240-32 4
9 100562-250 BEARING 2.5 ID GAR-MAX GM4048-40 2
10 100564-000 THRUST WASHER 2 IN ID 2
11 011941-005 FITTING 6MB-6MJ 2
12 011254-010 SCREW 3/8-16 UNC HHC X 1-1/4 LG 12
13 011238-006 WASHER SPLIT LOCK 3/8 16
14 011254-006 SCREW 3/8-16 UNC HHC X 3/4 LG 4
16 011257-020 SCREW 5/8-11 UNC HHC X 2.5 LG 4
17 011239-010 WASHER 5/8 FLAT ASTM A325 4
18 011248-010 LOCKNUT 5/8-11 UNC ESNA 4
19 100562-100 BEARING 1 TO GAR-MAX GM1620-032 2
