Upright SB60 - Page 119

Illustrated Parts Breakdown
Section
SB60 Work Platform 6-27
6.2
ENGINE MODULE ASSEMBLY, GAS
100013-000
ITEM PART DESCRIPTION QTY.
201 100338-000 CONNECTOR, MALE (21 PIN) 1
202 100338-005 BOOT 1
205 100338-012 CONTACT, 12 GA SOCKET 3
207 100338-014 CONTACT, 16 GA SOCKET 15
208 029484-099 WIRE, 8 GA RED FT 6
209 068764-000 PLUG, SEALING 3
210 067990-002 LOCKING WEDGE, MALE 1
211 067990-003 LOCKING WEDGE, FEMALE 1
212 029452-099 WIRE, 16 GA. BLACK FT 6
213 029451-099 WIRE, 16 GA WHITE FT 6
214 029454-099 WIRE, 16 GA RED FT 6
215 029456-099 WIRE, 16 GA YELLOW FT 6
216 029453-099 WIRE, 16 GA ORANGE FT 6
217 029450-099 WIRE, 16 GA BLUE FT 6
218 029479-099 WIRE, 16 GA WHITE/BLACK FT 6
219 029472-099 WIRE, 12 GA BLACK FT 12
220 005491-099 WIRE, 16 GA GREEN/BLACK FT 6
221 029477-099 WIRE, 16 GA ORANGE/BLACK FT 6
222 029475-099 WIRE, 16 GA BLUE/BLACK FT 6
223 029351-099 WIRE, 16 GA BLACK/WHITE FT 6
224 029352-099 WIRE, 16 GA RED/WHITE FT 6
225 029353-099 WIRE, 16 GA GREEN/WHITE FT 6
226 029354-099 WIRE, 16 GA BLUE/WHITE FT 6
227 029470-099 WIRE, 12 GA RED FT 18
228 064195-080 BATTERY CABLE ASSY X 80 LG 2
229 064195-032 BATTERY CABLE ASSY X 32 LG 1
230 029931-003 CONN. FEM PUSH (.25) 16-14 GA 7
231 029617-002 CONN. MALE PUSH (.25) 16-14 GA 6
232 029601-039 CONN. RING TERM. 0-5/16 12-10 GA 6
233 029601-012 CONN. RING TERM. #8 0-16-14 GA 1
234 029620-003 CONNECTOR, BUTT 10-12 GA 4
235 029610-006 CONN. FORK TERM, #8 0-14-16 GA 18
236 029825-002 DIODE 1
237 014435-001 BATTERY TERMINAL 2
238 029616-003 CONN. FEMALE PUSH 12-10 3
239 029419-099 WIRE, 12 GA RED/GRN 6
240 029418-099 WIRE, 12 GA RED/BLK 12
241 029601-025 CONN. RING TERM 0-5/16 8 GA 4
ENGINE REPAIR PARTS
SB60, GAS
ITEM PART DESCRIPTION QTY.
* 100200-005 OIL FILTER 1
* 100200-006 FUEL FILTER 1
* 100200-007 FAN BELT 1
* 100200-008 IGNITION 1
* 100200-009 DISTRIBUTOR 1
* 100200-010 STARTER BOLTS 1
* 100200-011 STARTER 1
* 100200-013 ALTERNATOR 1
* 100200-014 ALTERNATOR BRACKET 1
* 100200-015 WATER PUMP 1
* 100200-016 WATER PUMP GASKET 1
* 100200-017 WATER HOSE, TOP 1
* 100200-018 WATER HOSE, BOTTOM 1
* 100200-019 THERMOSTAT 1
* 100200-020 THERMOSTAT GASKET 1
* 100200-021 SPARK PLUGS 1
* 100200-022 SPARK PLUG WIRES 1
* 100200-023 CARBURETOR 1
* 100200-024 CARBURETOR GASKET 1
* 100200-025 DISTRIBUTOR CAP 1
* 100200-026 DISTRIBUTOR ROTOR 1
* 100200-027 GOVERNOR ASSEMBLY 1
* 100200-028 OIL DRAIN PLUG 1
* 100200-029 OIL DRAIN WASHER 1
* 100200-030 INT. EXHAUST MANIFOLD GASKET 1
* 100200-031 HEAD GASKET 1
* 100200-032 VALVE COVER GASKET 1
* 100200-033 THROTTLE CONTROL 1
* 100200-034 ACTUATOR LINKAGE 1
* 100200-035 GOVERNOR CONTROL 1
* 100200-036 COUPLER KIT-SPLINE 1
