Illustrated Parts Breakdown
Section
SB60 Work Platform6-30
6.2
CONTROL MODULE ASSEMBLY
100014-000 GAS/100014-001 DIESEL
ITEM PART DESCRIPTION QTY.
1 100176-000 CONTROL MODULE TRAY WELDMENT 1
2
100270-001 FUEL TANK ASSY (GAS) 1
100270-000 FUEL TANK ASSY (DSL) 1
3 100274-000 TANK STRAP 2
4 100271-000 HYDRAULIC RESERVOIR ASSY 1
5 100294-000 BATTERY HOLD DOWN 1
6 100293-000 BATTERY AUX 12V 1
7 100239-000 POWER UNIT (EMERGENCY LOWERING) 1
8 011937-006 FITTING SWIVEL 90° 10FJX-10MJ 1
9 011934-004 FITTING AERO 2062-6-6S 1
10 027972-000 SOLENOID 1
11
029945-018 LEVEL SENSOR (GAS & DSL DOM) REF
029945-013 LEVEL SENSOR (DSL EURO) REF
12
100019-000 LOWER CONTROL BOX ASSY (GAS) 1
100018-000 LOWER CONTROL BOX ASSY (DSL) 1
13 100216-000 BATTERY SUPPORT BRACKET 2
14 100313-000 TANK TAB 1
15 011252-008 SCREW HHC GRS 1/4-20 UNC X 1 10
16 014996-004 WASHER 1/4 SAE FLAT PLTO 16
17 011248-004 NUT HEX ESNA 1/4-20 UNC 12
18 011253-012 SCREW HHC GRS 5/16-18 UNC X 1-1/4 2
19 014996-005 WASHER 5/16 SAE FLAT PLTO 6
20 011248-005 NUT HEX ESNA 5/16-18 UNC 2
21 011240-006 WASHER, STD FLAT 3/8 4
22 011248-006 NUT HEX ESNA 3/8-16 UNC 2
24 100295-000 J-BOLT 2
25 011254-006 SCREW HHC GRS 3/8-16 UNC X 3/4 2
26 011250-004 NUT HEX 1/4-20 UNC 2
27 064195-010 BATTERY CABLE ASSY X 10 REF
28 064195-019 BATTERY CABLE ASSY X 19 REF
29 010154-000 COVER, BATTERY TERMINAL 2
