Illustrated Parts Breakdown
Section
SB60 Work Platform6-42
6.2
ITEM PART DESCRIPTION QTY.
218 015790-007 PIN CONTACT 14-16G 3
219 066807-001 ALARM 107DB 1
220 100319-000 HINGE SOUTHCO C6-30 2
221 026553-004 RIVET PDP 3/16 DIA X .375 GRIP 8
222 011240-002 WASHER #8 FLAT 8
223 068698-002 TERMINAL BLOCK (BLUE) 2
224 011715-006 SCREW RD HD MACHINE #6-32 X 3/4 LG 6
225 011240-001 WASHER #6-32 12
226 011248-047 LOCKNUT #6-32 6
227 100337-099 O-RING CORD 3/16 FT 3.5
229 068773-002 JUMPER, 2 PIN 4
230 100707-000 INNER STIFFENER 1
231 100708-000 OUTER STIFFENER 1
232 011252-006 SCREW 1/4-20 UNC HHC X 3/4 LG 1
233 011240-004 WASHER 1/4 FLAT 2
234 011248-004 LOCKNUT 1/4-20 UNC 1
301 029452-099 WIRE, 16 GA BLACK FT 10
302 029451-099 WIRE, 16 GA WHITE FT 10
303 029454-099 WIRE, 16 GA RED FT 10
304 029457-099 WIRE, 16 GA GREEN FT 10
305 029450-099 WIRE, 16 GA BLUE FT 10
306 029479-099 WIRE, 16 GA WHITE/BLACK FT 10
307 029478-099 WIRE, 16 GA RED/BLACK FT 10
308 005491-000 WIRE, 16 GA GREEN/BLACK FT 10
309 029351-099 WIRE, 16 GA BLACK/WHITE FT 10
310 029352-099 WIRE, 16 GA RED/WHITE FT 10
311 029353-099 WIRE, 16 GA GREEN/WHITE FT 10
312 029354-099 WIRE, 16 GA BLUE/WHITE FT 10
313 029355-099 WIRE, 16 GA BLACK/RED FT 10
314 029358-099 WIRE, 16 GA BLUE/RED FT 10
315 029356-099 WIRE, 16 GA WHITE/RED FT 10
316 029360-099 WIRE, 16 GA ORANGE/GREEN FT 10
317 029456-099 WIRE, 16 GA YELLOW FT 10
318 029477-099 WIRE, 16 GA ORANGE/BLACK FT 10
319 029475-099 WIRE, 16 GA BLUE/BLACK FT 10
320 029359-099 WIRE, 16 GA RED/GREEN FT 10
321 029455-099 WIRE, 16 GA BROWN FT 10
322 029362-099 WIRE, 16 GA RED/BLACK/WHITE FT 10
323 029453-099 WIRE, 16 GA ORANGE FT 10
324 029488-099 WIRE, 16 GA, 6 COND FT 11
325 029461-099 WIRE, 14 GA BLACK FT 10
326 029466-099 WIRE, 14 GA WHITE FT 10
327 029460-099 WIRE, 14 GA RED FT 10
328 029825-002 DIODE, 5 AMP, 400V 15
329 029601-013 CONN, RING 16-14 #10 23
330 029610-006 CONN, FORK 16-14 #6 59
331 029616-002 CONN, FEMALE PUSH 16-14 4
332 029490-099 WIRE 16 GAUGE, 2 COND, TYPE SO FT 5
UPPER CONTROLLER ASSEMBLY
GAS SB60
100017-000
ITEM PART DESCRIPTION QTY.
1 100325-000 DRIVE CONTROLLER 1
* 066786-015 BOOT, ROCKER SWITCH 1
* 066786-024 STEERING MICRO SWITCH 1
* 063913-001 BOOT, HANDLE 1
* 068592-008 DRIVE MICRO SWITCH 1
* 066786-011 HANDLE HALF, FRONT 1
* 066786-012 HANDLE HALF, REAR 1
* 066786-013 GASKET, HANDLE 1
* 066786-021 SWITCH, PUSH BUTTON 1
2 100326-000 LIFT CONTROLLER 1
3 100327-000 EXTEND CONTROLLER 1
* 068592-008 DRIVE MICRO SWITCH 1
4 100309-000 UPPER CONTROL BOX 1
5 100310-000 STIFFENER, UPPER CONTROLLER 1
6 012797-000 SWITCH TOGGLE SPST MAINTAINED 1
7 012798-000 SWITCH TOGGLE SPDT MOMENTARY 3
8 068590-000 BASE INDICATOR SPDT MOMENTARY 2
9 068591-001 LAMP T-2 1/2 2
10 068595-002 LENS AMBER 1
11 068595-001 LENS RED 1
12 064446-003 EMERGENCY STOP BUTTON 1
13 064443-002 CONTACT BLOCK NC 3
14 064417-001 FLANGE MOUNT 2
15 012798-005 SWITCH TOGGLE DPST MOMENTARY 1
16 029871-001 SWITCH TOGGLE SPDT MAINTAINED 1
17 067654-000 PUSH BUTTON, FLUSH (BLACK) 1
18 064443-001 CONTACT BLOCK NO 1
201 100309-000 UPPER CONTROL BOX REF
202 029925-002 CONNECTOR CABLE 1/2 NPT 2
203 029939-002 LOCKNUT 1/2 NPT 2
204 100334-000 SWITCH, LEVER 1
205 067893-000 MOUNTING RAIL DIN X 13 LG 1
206 067660-006 TERMINAL END 2
207 067661-001 RELAY SPDT 12 VDC 5
208 067661-004 RELAY 4PDT 12 VDC 1
209 068698-001 TERMINAL BLOCK (TAN) 23
210 068698-000 TERMINAL BLOCK (ORANGE) 2
211 068698-004 END CAP, CONTACT BLOCK 1
212 067662-001 RELAY SOCKET SPDT 5
213 067662-004 RELAY SOCKET 4PDT 1
214 067662-005 RETAINER CLIP ASSY 5
215 067662-007 RETAINER CLIP ASSY 1
216 015790-006 CONNECTOR RECEPTACLE 1
217 015790-004 PIN CONTACT 16-18G 27
