Illustrated Parts Breakdown
Section
SB60 Work Platform6-50
6.2
LOWER CONTROLLER ASSEMBLY,
GAS
100019-000
ITEM PART DESCRIPTION QTY.
1 100307-000 ENCLOSURE 1
3 068582-020 CIRCUIT BREAKER, 20 AMP 3
4 012798-000 TOGGLE SWITCH, SPDT 7
5 012798-005 TOGGLE SWITCH, DPDT 1
6 100335-000 SELECTOR SWITCH, KEY OPERATED 1
* 068807-010 KEY 1
7 064417-001 LATCH PLATE 1
8 064443-001 CONTACT BLOCK, NC 2
9 064446-003 OPERATOR, RED "MUSHROOM" BUTTON 1
10 100331-000 OIL PRESSURE GAUGE 1
11 100330-000 TEMPERATURE GAUGE 1
12 015752-000 HOUR METER 1
13 067662-001 BASE, RELAY SINGLE POLE 17
14 067661-001 RELAY, SINGLE POLE 17
15 067662-005 RETAINER CLIP, RELAY 17
16 067893-005 DIN RAIL 10-1/2" LENGTH 2
17 100316-000 MOUNTING PLATE 1
18 068698-001 TERMINAL BLOCK, TAN 43
19 068698-000 TERMINAL BLOCK, ORANGE 2
20 068698-002 TERMINAL BLOCK, BLUE 6
21 029925-001 CORD GRIP 3
22 100336-000 CONTROLLER "SUPER-FLEX" KIT 1
23 100299-000 SPACER 3
24 068698-004 END SECTION 2
25 067660-006 END BLOCK, LOCKING 6
26 026551-005 POP RIVET 1/8" DIA (3/16-1/4 GRIP) 6
27 066516-008 PLUG, 1/2" DIA 1
28 012798-006 TOGGLE SWITCH 1
29 029939-003 LOCKNUT 3/4" NPT 3
31 011708-004 SCR, RD HD #8-32 UNC X 1/2 6
32 011240-003 WASHER, FLAT #10 6
33 068860-000 CONTACT BLOCK, NO DOUBLE 2
34 068773-002 JUMPER, 2 PIN 1
35 100315-000 MOUNTING BRACKET 1
36 011252-006 SCREW, HHC 1/4-20 X 3/4 4
37 011248-004 LOCKNUT, 1/4-20 UNC ESNA 4
38 067893-006 DIN RAIL 8-1/2" LENGTH 1
39 100298-000 NUMBER STRIP #1 - #50 1
40 100336-015 WIRE HARNESS 2
41 100316-016 WIRE HARNESS 1
42 068773-003 JUMPER, 3 PIN 1
43 060214-099 CABLE 16 GA 15 COND FT 11
44 100338-001 CONNECTOR, FEMALE 21 PIN 1
45 100338-011 CONNECTOR, 12 GA PIN 3
46 100338-013 CONNECTOR, 16 GA PIN 15
47 100338-005 BOOT 1
48 068764-000 PLUG SEALING 3
ITEM PART DESCRIPTION QTY.
201 029452-099 WIRE, 16 GA BLACK FT 10
202 029451-099 WIRE, 16 GA WHITE FT 10
203 029454-099 WIRE, 16 GA RED FT 10
204 029457-099 WIRE 16 GA GREEN FT 10
205 029479-099 WIRE, 16 GA WHITE/BLACK FT 10
206 029478-099 WIRE, 16 GA RED/BLACK FT 10
207 005491-099 WIRE, 16 GA GREEN/BLACK FT 10
208 029477-099 WIRE, 16 GA ORANGE/BLACK FT 10
209 029352-099 WIRE, 16 GA RED/WHITE FT 10
210 029353-099 WIRE, 16 GA GREEN/WHITE FT 10
211 029354-099 WIRE, 16 GA BLUE/WHITE FT 10
212 029358-099 WIRE, 16 GA BLUE/RED FT 10
213 029356-099 WIRE, 16 GA WHITE/RED FT 10
214 029360-099 WIRE, 16 GA ORANGE/GREEN FT 10
215 029475-099 WIRE, 16 GA BLUE/BLACK FT 10
216 029453-099 WIRE, 16 GA ORANGE FT 10
217 029450-099 WIRE, 16 GA BLUE FT 10
218 029456-099 WIRE, 16 GA YELLOW FT 10
222 029470-099 WIRE, 12 GA RED FT 10
223 029466-099 WIRE, 14 GA WHITE FT 10
224 015747-002 DIODE, 1 - 1-1/2 AMP 1000 VOLT 6
225 029825-003 DIODE, 3 AMP 400 VOLT 23
227 029447-099 CABLE, 3 COND/16 AWG FT 7
228 100321-099
CABLE, 34 COND/18 GA
-3 COND/10 GA
FT 8 0
229 060214-099 CABLE, 15 COND/16 AWG FT 10
230 060214-099 CABLE, 15 COND/16 AWG FT 14
231 029490-099 CABLE, 2 COND/16 AWG FT 10
232 100380-000 SWITCH, LIFT INTERLOCK 1
233 029620-002 CONN BUTT 16-14 GA 10
234 029601-039 CONN RING (5/16 DIA) 12-10 GA 1
235 029617-003 CONN MALE PUSH (.25) 12-10 GA 2
236 029610-002 CONN FORK (#6 DIA) 16-14 GA 127
237 029610-003 CONN FORK (#6 DIA) 12-10 GA 3
238 029601-012 CONN RING (#8 DIA) 16-14 GA 6
239 029931-003 CONN FEM PUSH (.25) 16-14 GA 2
240 029931-005 CONN FEM PUSH (.25) 12-10 GA 6
241 029610-001 CONN FORK 22-18 GA #6 1
242 029601-019 CONN T&B RC 367 12 GA RING 1
